Brass Low Pressure Die Casting Machine: Smart Control, High
Efficiency
Product Description:
Features:
Precision Casting: Utilize low-pressure casting technology to accurately cast
complex brass components in a controlled environment. This ensures
a high degree of precision in the final product's shape and
dimensions, reducing the need for subsequent machining.
Efficient Production: Brass low-pressure casting machines can complete a large number
of casting tasks in a short period, increasing production
efficiency. This is particularly important for industries requiring
large-scale production.
Material Advantages: Brass, being a primary material for brass low-pressure casting,
offers excellent electrical conductivity, thermal conductivity, and
corrosion resistance. This makes brass an ideal choice for
manufacturing products such as bathroom accessories, valves, water
meters, and more.
Automated Processes: Equipped with intelligent control systems that can automate
casting, pressure replenishment, and unloading processes, reducing
manual intervention and improving production consistency and
efficiency.
Environmental Performance:Use electric furnace control systems, which reduce energy
consumption compared to other casting methods, making them more
environmentally friendly.
Rapid Mold Change Capability: Allowing for quick mold replacements to accommodate different
product requirements, enhancing production flexibility.
High-Density Castings: Automatic pressure replenishment functions, which help increase
the density of castings, reducing the occurrence of cracks and
pores.
Technical Parameters:
| Properties | Parameters |
| Equipment Size:L*W*H | 5200*5000*3600mm |
| Total Weight | 13T |
| Total power | 125KW |
| Voltage | 380V |
| Max. Die Dimensions | 600*400*240mm |
| Max. Die Thickness | 2*120mm |
| Max. Die Opening stroke | 370mm |
| Max.Die Weight | 200Kg |
| Max. force of die closing | 2400KG |
| Max. force of ejector | 500KW |
| Max. die ejector stroke | 48mm |
| Furnace Melting rate | 350KG/H |
| Furnace Capacity | 1800KG |
| Furnace Inductors | 3*35KW |
| Hydraulic Motor Power | 8.7KW |
| Hydraulic Rated Pressure | 8Mpa |
| Hydraulic fluid temperature | ≤52℃ |
| Cooling system Water PH value | 7~8.5 |
| Cooling system Pressure | 3-5bar |
| Cooling system Temp. | 20±2℃ |
| Cooling system Flow | ≥400L/Min ≤600L/Min |
| Air pressure Compressed air pressure | 0.5-0.6Mpa |
| Air pressure Compressed air consumption | 15m³/H |
Applications:
Manufacturing Bathroom Accessories: Brass low-pressure casting machines are commonly used to
manufacture bathroom accessories such as faucets, showerheads,
faucet handles, and components for other sanitary equipment. The
high corrosion resistance and decorative properties of brass make
it an ideal material for bathroom products.
Water Meter Manufacturing: Brass low-pressure casting machines are used to produce the
casings and internal components of water meters. Brass's excellent
thermal conductivity and electrical conductivity make it an ideal
material for water meters, aiding in accurate water measurement and
recording.
Valve Manufacturing: Valves play a crucial role in industrial processes, and brass
low-pressure casting machines are employed to manufacture
high-quality valve components, ensuring their reliability and
durability.
Automotive Components: In the automotive manufacturing industry, brass low-pressure
casting machines can be used to produce various components such as
engine parts, brake components, and transmission system parts.
Instruments and Gauges: Some high-precision instruments and gauges require brass parts to
ensure their accuracy and stability.
Support and Services:
Technical Support and Service for Low Pressure Die Casting Machine
We provide technical support and service for low pressure die
casting machine, including:
- Troubleshooting for low pressure die casting machine
- Preventive maintenance for low pressure die casting machine
- Repair and replacement of low pressure die casting machine parts
- Installation and commissioning of low pressure die casting machine
- Training on how to operate low pressure die casting machine
- Technical advice on low pressure die casting machine
- Other services related to low pressure die casting machine
Company profile:
Xiamen Dingzhu Intelligent Equipment Co., Ltd. (est. 2016) is a
global leader in intelligent manufacturing solutions specializing
in low-pressure die casting, grinding, polishing, and automation
systems. Our core offerings include automatic LPDC machines,
robotic cell grinding/polishing systems, CNC polishing equipment,
and turnkey production lines, serving industries such as water
meter casting, door locks, auto parts, and precision deburring.
With exports to 30+ countries (Turkey, India, Mexico, USA,
Southeast Asia, etc.) and partnerships with top brands like Kohler
and TOTO, we empower manufacturers with safer, greener, and smarter
production through proprietary technologies like dynamic pressure
control and multi-axis robotic algorithms. 50+ patents and a 60+
R&D team drive innovations in low-pressure casting and robotic
automation. We deliver end-to-end solutions—from mold design (CAE
simulation) to lean factory layouts—backed by 24/7 global support,
localized service centers (India, Turkey, Egypt), and 48-hour
on-site assistance. CE-certified with strict material inspection
and a 1-year warranty, we prioritize eco-friendly practices and
operational excellence. Committed to "liberating workers' hands,"
Dingzhu envisions leading the future of intelligent automation,
helping clients achieve productivity breakthroughs and sustainable
growth. Partner with us to transform your manufacturing with
cutting-edge technology and world-class expertise.
Packing and Shipping:
Packaging and Shipping of Low Pressure Die Casting Machine
The Low Pressure Die Casting Machine will be packed in a wooden
box, which is reinforced with steel straps for extra protection.
Packing materials used for the box include bubble wrap and
polyethylene foam. Upon completion of packing, the box will be
sealed with tape for further protection.
The Low Pressure Die Casting Machine will be shipped via air
freight, sea freight, or land transportation, depending on
customer’s needs and requirements. The shipping company and package
will be carefully chosen to ensure safe and timely delivery of the
product.
