    CNC Control Robotic Buffing Machine / Polishing / Finishing Machine For Brass Casted Faucets

    Ask Lasest Price
    Brand Name : DZ
    Model Number : NC-62
    Certification : CE ISO
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30sets /per day
    Delivery Time : 30days
    • Product Details
    • Company Profile

    CNC Control Robotic Buffing Machine / Polishing / Finishing Machine For Brass Casted Faucets

    Deburring, Polishing, Brightening For Brass Casted Faucets, Zamak,Zamak Faucets, Shower Heads And Any Sanitary


    I.TECHNICAL PARAMETERS

    NoItemsSpecifications
    1Dimensions (L*W*H)3000*3100*2900mm
    2Machine Power17KW
    3Rated Voltage380V
    4Max. Diameter of polishing wheel600mm
    5Min. Diameter of polishing wheel400mm
    6X-Axis travel (mm)1100
    7Y-Axis travel (mm)900
    8Z-Axis travel (mm)700
    9U-Axis travel (mm)±60°
    10V-Axis travel (mm)±360°
    11W-Axis travel (mm)±360°
    12Max.speed X axis20m/min
    13Max.speed Y axis20m/min
    14Max.speed Z axis20m/min
    15Max.speed U axis30°/sec.
    16Max.speed V axis30°/sec.
    17Max.speed W axis30°/sec.

    II.FEATURES

    Sypical products to process: Brass casted faucets, zamak
    levers,zamak faucets, shower heads and any sanitary ware
    Rotary transfer with CNC control system
    Multi-purpose Machine: Deburring, Polishing, Brightening Satin
    Easy and intuitive teach-in programming system
    Pressure control: disc wear control with automatic
    compensation
    High productivity: 4 simultaneous part processing
    High adaptability: Multiple geometries processin
    Ultra flexible: multi part flow. Up to 4 simultaneous parts processing
    Model change in seconds
    Quick change of consumables and grippers
    Low operating cost: energy efficient, minimized consumption of discs and compound
