Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty

    Buy cheap Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty from wholesalers

    Buy cheap Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty from wholesalers
    • Buy cheap Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty from wholesalers

    Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty

    Ask Lasest Price
    Brand Name : DZ
    Model Number : NC-64
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30sets/per month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    Buffing Wheel CNC Polishing Machine For Hardware Sanitary Ware , 1 Year Warranty

    Buffing Wheel CNC Polishing Machine advanages:

    1. The automatic polishing machine is an exclusive polishing system consisting 4 manipulators with of 6 axises rotary; high flexibility and high product efficiency.

    2. Automatic double open fixture, 360 degree freely rotating fixture,polish without any blind side.

    3. Two Synchronous polishing positions, four positions, no loading and unloading time, increase the polishing efficiency.

    4. China Easy Operation CNC Polishing Machine Gray White For Hardware Sanitary Ware distributor.

    II:Main technical parameters
    #ItemParameterRemarks
    1Size3000×3160×2772(L×W×H)
    2Power16.25KW
    3Rated Voltage380V 50Hz
    4Max. Polishing Mop Diameter600mm
    5Min. Polishing Mop Diameter400mm
    6X Axis Travel1100
    7Y Axis Travel900
    8Z Axis Travel700
    9U Axis Travel±60°
    10V Axis Travel±360°
    11Operating Voltage380V
     Table Size (LxW)2740*375mm
     Height from Ground (without fixture)880mm
     Jig Rotating Speed20RPM
     Station Size/Working Dia (max)350mm
     Station Rotational speed Motor1500rpm
    IIIBASIC EQUIPMENT
    #ItemBrandRemark
    1Motion control systemPROMAX Italy
    2Servo motorPROMAX Italy
    3Variable frequency compensation system+Control cardAELTA
    4Cloth wheel motor spindleSIEMENS
    5Main low voltage electricalSCHNEIDER
    6Linear guide rail and screwHIWIN
    7Reduction boxRossi Italy
    8BearingNSK
    9Steering gear of fixtureTAIWAN
    10Components clampingPenumatic
    11Table TypeMovable - table moving by the screw rod/ball screw. Driven by servo motor

    Sample showing
