Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy

    Buy cheap Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy from wholesalers

    Buy cheap Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy from wholesalers
    • Buy cheap Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy from wholesalers
    • Buy cheap Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy from wholesalers
    • Buy cheap Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy from wholesalers

    Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy

    Ask Lasest Price
    Brand Name : DZ
    Model Number : 2-Manipulator
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1 set/per month
    Delivery Time : 60days
    • Product Details
    • Company Profile

    Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy

    Custom Low Pressure Die Casting Machine Silvery Grey Color For Brass Alloy / Zinc Alloy


    To fulfill the different capacity requirement of customers, we have 1-manipulator and 2-manipulators models for customer options.


    Advanages:


    1. High quality casting and high-precision repeatability , automated casting with servo motor driving, linear guiding rail system;

    2. High capacity ranges 400~450 castings per shift (8hrs);

    3.Quick die change flange, 5 mins by munually ;

    4. Furnace heating method: gas burner is standard and elctricity for option;

    5. Max. die diemension 550*400mm;

    6. Whole set machine cooled by cooling water for a efficiency cooling, highly improve inductors service life;

    7. Zinc Oxide dust cleaning unit for furnace cleaning;

    8. Industrial PC control with Ethernet cables, die casting programs up to 200 saved, recording & tracking furnace temperature;

    9 .Cost-efficient production ( reduced melting loss,multiple die,one-man operation,increased yield);

    10. Humanization of the work station (ergonomic design of the work station,minimizing of heat,noise and danger of accident)



    2- Manipulators Low Pressure Die Casting Machine Technical Parameters


    Code


    Item


    Specifications

    1

    Dimension ( L*W*H)

    7000*7000*3680

    2

    Machine Power

    180KW

    3

    Rated Voltage

    380V

    4

    Manipulator Quantity

    2

    5

    Maximum Weight of Die

    180KG

    6

    Maximum Dimension of Die

    500*400*250

    7

    Furnace Power

    2*80KW

    8

    Furnace Melting Capacity

    520Kg

    9

    Furnace Quantity

    1

    10

    Die Cleaning Box Quantity

    1

    11

    Feeder Quantity

    1

    12

    Blackwash Tank Quantity

    1

    13

    Hoist Quantity

    1

    14

    Lift Tube Quantity

    2

    15

    Pneumatic Pressure

    6KG

    16

    Water Pressure

    3KG

    17

    Maximum Furnace Temperature

    1250℃

    18

    Cooling Water Temperature

    20±2℃

    19

    Maximum Speed of Manipulator

    9R/Min.

    20

    Maximum Die Clamping Stroke

    370mm

    21

    Die Bath Angle

    0-90º

    22

    Ejector Pin Pressure

    540KG

    23

    Ejector Pin Stroke

    40mm

    24

    Pouring Pressure

    50-1200bar

    25

    Maximum Lift Weight of Hoist

    500kg

    The LPDC equipment consisting of main components: casting device, induction furnace, receiving car, graphite bath, die cleaning device,crane, manipulators, hydraulic and drives system, pneumatic system, riser tube heating system and control system etc.


    Click the link to view video:

    https://www.youtube.com/watch?v=zmWTnfFq-mM
