    Silvery Grey Low Pressure Die Casting Machine High Productivity For Stainless Steel

    Ask Lasest Price
    Brand Name : DZ
    Model Number : 1-Manipulator
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1 set/per month
    Delivery Time : 60 days
    Certification : CE
    • Product Details
    • Company Profile

    Silvery Grey Low Pressure Die Casting Machine High Productivity For Stainless Steel

    Silvery Grey Low Pressure Die Casting Machine High Productivity For Stainless Steel


    Application:


    The Low Pressure Die casting machine are mainly for brass alloy and zinc alloy metal products, especially on faucets, valve bodies and sanitary fittings and accessories. To fulfill the different capacity requirement of customers, we have
    1-manipulator and 2-manipulators models for customer options.

    main components:

    casting device, induction furnace, receiving car, graphite bath, die cleaning device,crane, manipulators, hydraulic and drives system, pneumatic system, riser tube heating system and control system etc.


    Advanages:


    1. Operation Control System: With Siemens PLC control device;Manipulator is with servo motor driving unit, linear guilding rail system, to move the manipulator in horizontal and vertical direction: faster, more stable and high precision control performances.

    2. Induction furance: power is 105KW; Large melt content up to 1800kg,;Melting capacity is 350KG/H, stepless power adjustment; With 3*35KW inductors, each inductor is water cooling, water flow detection device on water jackets; Induction furnace heating methods: standard with gas burner, electricity heating for option ( extra cost); Hydraulic opening device mounted on furnace cover..

    3. Receiving car: with performances of moving up-down; forward & backward; Transport the casting products to storage vehicles directly..

    4. Die Cleaning Chamber: shot blasting device (copper powder blasting) for the cleaning of the dies.; The dies can be moved to cleaning chamber automatically for cleaning process @ heavy oxidized contaminations condition.

    5. Crane with electric hoist: Effective lifting weight 500kg; Crane is used to lift the furnace cover for furnace cleaning, maintenance etc.

    6.Graphite Bath: With performances of Constant temperature and graphite agitation. With 2 sperated tanks, tubes and agitators made of stainless steel material( SUS 316L). Used for die cooling and coating; Graphite coating is for easier pieces removal and die's temperature control.


    Technical Parameters


    1-Manipulator Low Pressure Die Casting Machine Technical Parameters
    CodeItemSpecifications
    1Dimensions ( L*W*H)5000*4600* 3400
    2Machine Power125KW
    3Rated Voltage380V
    4Manipulator Quantity1
    5Maximum Weight of Die180KG
    6Maximum Dimension of Die500*400*250
    7Furnace Power3*35KW
    8Furnace Melting Capacity350Kg
    9Furnace Quantity1
    10Die Cleaning Box Quantity1
    11Feeder Quantity1
    12Blackwash Tank Quantity1
    13Hoist Quantity1
    14Lift Tube Quantity3
    15Pneumatic Pressure6KG
    16Water Pressure3KG
    17Maximum Furnace Temperature1250℃
    18Cooling Water Temperature20±2℃
    19Maximum Speed of Manipulator20m/ Min.
    20Maximum Die Clamping Stroke370mm
    21Die Bath Angle0-90º
    22Ejector Pin Pressure540KG
    23Ejector Pin Stroke40mm
    24Pouring Pressure50-1200bar
    25Maximum Lift Weight of Hoist500kg
