    Full Automatic Stainless Steel Buffing Machine For Automobile Industry

    Ask Lasest Price
    Brand Name : DZ
    Model Number : Robot
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30units/per month
    Delivery Time : 2weeks
    • Product Details
    • Company Profile

    Full Automatic Stainless Steel Buffing Machine For Automobile Industry

    Full Automatic Stainless Steel Buffing Machine For Automobile Industry

    I. Introduction to products

    1. Full automatic control,Repeatable editing,Able to complete various polishing operations in 3D space.

    2. Sand belt machine:There are several available grinding contact wheels. In the grinding process, the robot can control the speed of the sand belt, automatically adjust the tensioning force of the sand belt, and automatically select the currently available contact wheel.(Users can freely configure the number of sand belt grinder according to the product)

    3. Double station automatic feeding table:Two stations can put the same products or different products at the same time. The robot can automatically identify and work according to different procedures.

    4. Fixture shifter:Pneumatic drive, with pneumatic, cable rotation function, displacement detection function, to avoid the position of the transformer in the wrong equipment operation, damage the machine or PU wheel.

    5. Control system:Automatic line speed compensation, sand belt deviation correction, automatic compensation grinding pressure and remote fault diagnosis and repair functions.


    II: TECHNICAL PARAMETERS
    To fulfill the different product weight and sizere quirement,different requirements for belt sander of customers,we have 4 models for customer options.
     20GA Specifications20GBSpecifications35GSpecifications50GSpecifications
    Robot CellFUNACFUNACFUNACFUNAC
    Robot Model20iA/2020iA/2020iA/3520iA/50
    Rated Voltage380V380V380V380V
    Machine Power7.6KW10.5KW11KW16KW
    Sand Belt Machine Quantity1222
    Sand Belt Quantity4444
    Sand Belt Dimensions3000mm×43000mm×44000mm×44000mm×4
    Feed Table1111

    Application
