    Easy Operation Automatic Metal Polishing Machine For Auto Spare Parts

    Ask Lasest Price
    Brand Name : DZ
    Model Number : NC64-L
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 Set/Sets per Month
    Delivery Time : 30 work days
    Certification : CE ISO
    • Product Details
    • Company Profile

    Easy Operation Automatic Metal Polishing Machine For Auto Spare Parts

    Automatic polishing machine for Auto spare parts Locks and door handles All kids of metals and jewelry accessory

    Feature:

    1. The automatic polishing machine is an exclusive polishing system consisting 4 manipulators with of 6 axises rotary; Multiple stations simultaneous operation high flexibility and high product efficiency.

    2. The control system adopts PROMAX motion control technology from Italy,stable propeert,high control accracy.

    3. Software: Programmable, with protable handed device, contains manually mode to simulate the workmanship polishing and record the track; 4 4. Polishing pressure and wear compensation control performance: When the polishing cloth wheel is worn out, the system can detect that the torque becomes smaller and automatically the compensation in all direction

    5. Linear speed compensation: When the outer diameter of the cloth wheel is reduced, the system automatically increases the speed and compensation;

    6. Program setting of add polishing wax:free setting of wax spraying time and frequency according to the characteristics of product.choice of slid wax or liquid wax

    7. Full digital control, Can store 50 programs.Programs can be saved and invoked at any time.

    8. CN/EN language display on Touch Panel. to set all parameters for an easy operation;fault codes display and alarm pages for quick troubles shooting and repair.

    TECHNICAL PARAMETERS

    No.ItemParameters
    1Dimensions (L*W*H)5000*3400*3000(L*W*H)
    2Machine Power35KW
    3Rated Voltage380V
    4Max. Diameter of polishing wheel600mm
    5Min. Diameter of polishing wheel400mm
    6X-Axis travel (mm)1200
    7Y-Axis travel (mm)1100
    8Z-Axis travel (mm)700
    9U-Axis travel (mm)±90°
    10V-Axis travel (mm)±360°
    11W-Axis travel (mm)±360°

    Photos of polished products
