    Interface Automatic Casting Core Making Machine With Motor Conveyor For Faucet

    Ask Lasest Price
    Brand Name : DZ
    Model Number : HZ-360
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 Sets per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Interface Automatic Casting Core Making Machine With Motor Conveyor For Faucet

    Human-machine Interface Automatic Casting Core Making Machine With Motor And Conveyor For Faucet


    Ⅰ FEATURE


    1. human-machine interface and imported high-quality electronic control and pneumatic components/hydraulic device to ensure accurate and reliable control and easy operation.


    2. there are three modes: manual, single action, and automatic.


    3. the shooting port is 70 degrees to the sand, away from the high-temperature area, so that the perforation is easy to clean manually.


    4. The machine is equipped with an integral moving mechanism of the base, which can make the base move along the X and Y axes so that the perforation of the opposite mold into the sand hole is more convenient and accurate.


    5. The movable die is equipped with the core pulling rack to meet the special requirements of the mold.


    6. The angle of the quicksand in the sand storage bucket reaches 70 degrees and is equipped with a vibrating motor. It is suitable for the use of collapsible core sand with poor fluidity in the copper casting and aluminum industry.


    7. With mold adjustment space, it is convenient to assemble different molds and reduce the requirements for the die size.


    Ⅱ TECHNICAL PARAMETERS


    CodeItemSpecification
    1Max. Weight of Sand Core8kg
    2Max. Size of Core Box ( L x W x H)(450*330*220)mm
    3Heating Plate ( L x W)(400*300)mm
    4Heating Power9.6kw
    5Downward Stroke of Ejection Head≤30mm
    6Stroke of Mold Opening≤300mm
    7Max. Stroke of Core Remove150mm
    8Conveyor ( L x W x H)(2200*450*100)mm
    9Total Power13.2kw
    10Rising Angle of Conveyor2°~4°
    11Speed of Transportation72mm/s
    12Machine Size ( L x W x H)(3500*1480*3400)mm
    13Speed of Lift (Single Time)35s
    14Weight of Lift ( Single Time)10kg
    15Total Weight2000kg
    16Hydraulic pressure50Kg/cm²

    Interface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For FaucetInterface Automatic Casting Core Making Machine With Motor Conveyor For Faucet


    FAQ

    Q: could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge


    Q: could you arrange the production education?
    A: Yes , we could and the buyer pay the charge


    Q:How long the guarantee?
    A: one year and charge for repair the whole life.


    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
