    High Efficiency Gravity Die Casting Machine For Sanitary

    Ask Lasest Price
    Brand Name : DZ
    Model Number : HZ-450
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 Sets per Month
    Delivery Time : 2week
    • Product Details
    • Company Profile

    High Efficiency Gravity Die Casting Machine For Sanitary

    Low Requirements For The Die Size And High Efficiency Gravity Die Casting Machine For Sanitary


    CHARACTERISTIC


    1) the circuit is controlled by PLC, the data is set by touch screen and all hydraulic components are imported.


    2) It is suitable for gravity die casting of brass and ferrous alloy.


    3) It can be frontal casting, side casting, twice casting and mixed casting.


    4) The cooling time of the mold can be adjusted separately.


    5) It facilitates the decomposition, combination and cleaning of dies.


    6) It has two functions manual and automatic circulation, the counter can be preset, to record the output of each shift.


    7) There is a die adjustment space to facilitate the application of different dies, and reduce the requirements for the die size.


    8) The machine can store the die casting operation programs and set the password accordingly.


    Ⅱ TECHNICAL PARAMETERS


    1MAX MOULD SIZE450mm
    2Max Mould Weight130KG
    3Longest Merger Distance≤250mm
    4Hydraulic Pressure40-60KPa
    5Side Casting Angie0º-90º
    6Frontal Casting Angle0º-110º
    7Hydraulic Oil163L
    8Total Power5.5KW
    9Installing Top Core Device20mm travel


    High Efficiency Gravity Die Casting Machine For SanitaryHigh Efficiency Gravity Die Casting Machine For SanitaryHigh Efficiency Gravity Die Casting Machine For SanitaryHigh Efficiency Gravity Die Casting Machine For SanitaryHigh Efficiency Gravity Die Casting Machine For SanitaryHigh Efficiency Gravity Die Casting Machine For Sanitary

    FAQ

    Q: Could you please arrange the installation and commissioning?
    A: Yes, we could and the buyer paid the charge.


    Q: Could you arrange the production education?
    A: Yes, we could and the buyer paid the charge.


    Q: How long is the guarantee?
    A: One year and charge for repair the whole life.


    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
