    Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing

    Ask Lasest Price
    Brand Name : DZ
    Model Number : NC-62
    Certification : CE ISO
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 units/per month
    Delivery Time : 2week
    • Product Details
    • Company Profile

    Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing

    Uniform Polishing Quality Two-stations Automatic Polishing Machine For Metal Surface Polishing


    ⅠCHARACTERISTIC


    Precision polishing.


    - Uniform polishing quality without deformation of the processed parts.


    - High production. Simultaneous polishing of two equal parts in each polishing cycle.


    - Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.


    - Quick replacement of the fixtures.


    - Quick replacement of the polishing mops.


    - Cost-reduction in the amount of fixtures.


    - Important reduction in mops and polishing compounds consumption.


    - Polishing system avoiding excessive temperature of the parts during the working process.


    - Quick and easy programming. Interactive Teach System.


    - High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.


    Ⅱ TECHNICAL PARAMETERS


    CodeItem

    Specifications

    1Dimensions (L*W*H)3000*3100*2900mm
    2Machine Power17KW
    3Rated Voltage380V
    4Max. Diameter of polishing wheel600mm
    5Min. Diameter of polishing wheel400mm
    6X-Axis travel (mm)1100
    7Y-Axis travel (mm)900
    8Z-Axis travel (mm)700
    9U-Axis travel (mm)±60°
    10V-Axis travel (mm)±360°
    11W-Axis travel (mm)±360°
    12Max.speed X axis20m/min
    13Max.speed Y axis20m/min
    14Max.speed Z axis20m/min
    15Max.speed U axis30°/sec.
    16Max.speed V axis30°/sec.
    17Max.speed W axis30°/sec.

    Uniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface Polishing

    FAQ

    Q: could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge


    Q: could you arrange the production education?
    A: Yes , we could and the buyer pay the charge


    Q:How long the guarantee?
    A: one year and charge for repair the whole life.


    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
