    Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

    Ask Lasest Price
    Brand Name : DZ
    Model Number : NC-64
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 units/per month
    Delivery Time : 2weeks
    • Product Details
    • Company Profile

    Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

    High Efficient Rotary Automatic Brass Tube CNC Polishing Machine No Need Dusting


    Precision polishing.

    - Uniform polishing quality without deformation of the processed parts.

    - High production. Simultaneous polishing of two equal parts in each polishing cycle.

    - Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

    - Quick replacement of the fixtures.

    - Quick replacement of the polishing mops.

    - Cost-reduction in the amount of fixtures.

    - Important reduction in mops and polishing compounds consumption.

    - Polishing system avoiding excessive temperature of the parts during the working process.

    - Quick and easy programming. Interactive Teach System.

    - High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

    TECHNICAL PARAMETERS

    NoItemsSpecifications
    1Dimensions (L*W*H)3000*3100*2900mm
    2Machine Power17KW
    3Rated Voltage380V
    4Max. Diameter of polishing wheel600mm
    5Min. Diameter of polishing wheel400mm
    6X-Axis travel (mm)1100
    7Y-Axis travel (mm)900
    8Z-Axis travel (mm)700
    9U-Axis travel (mm)±60°
    10V-Axis travel (mm)±360°
    11W-Axis travel (mm)±360°
    12Max.speed X axis20m/min
    13Max.speed Y axis20m/min
    14Max.speed Z axis20m/min
    15Max.speed U axis30°/sec.
    16Max.speed V axis30°/sec.
    17Max.speed W axis30°/sec.

    Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need DustingRotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting


    Product categories

    Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

    Company Profile

    Certifications

    FAQ

    Q: could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge


    Q: could you arrange the production education?
    A: Yes , we could and the buyer pay the charge


    Q:How long the guarantee?
    A: one year and charge for repair the whole life.


    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.High Precision Low Pressure Die Casting Machine For Brass Alloy
