    Industry Sand Core Shooting Machine For Metal Casting Production

    Ask Lasest Price
    Brand Name : DZ
    Model Number : HZ-360
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30sets / month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Industry Sand Core Shooting Machine For Metal Casting Production

    Industry Sand Core Shooting Machine For Metal Casting Production


    Excellent Quality Foundry Industry Sand Core Shooting Machine For Metal Casting Production


    Ⅰ CHARACTERISTIC


    1. Manual, semi-automatic and fully automatic.


    2. The core pulling function allowing for the special requirements of the die.


    3. The shooting port is 70 degrees to the sand, away from the high temperature area, so that the perforation is easy to clean manually.


    4. Mould cleaning function.


    5. Automatic sand feeding.


    6. Automatic unloading.


    7. Flexible mould installation.


    Ⅱ TECHNICAL PARAMETERS


    CodeItemSpecification
    1Max. Weight of Sand Core8kg
    2Max. Size of Core Box ( L x W x H)(450*330*220)mm
    3Heating Plate ( L x W)(400*300)mm
    4Heating Power9.6kw
    5Downward Stroke of Ejection Head≤30mm
    6Stroke of Mold Opening≤300mm
    7Max. Stroke of Core Remove150mm
    8Conveyor ( L x W x H)(2200*450*100)mm
    9Total Power13.2kw
    10Rising Angle of Conveyor2°~4°
    11Speed of Transportation72mm/s
    12Machine Size ( L x W x H)(3500*1480*3400)mm
    13Speed of Lift (Single Time)35s
    14Weight of Lift ( Single Time)10kg
    15Total Weight2000kg
    16Hydraulic pressure50Kg/cm²

    Industry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting ProductionIndustry Sand Core Shooting Machine For Metal Casting Production



    FAQ

    Q: could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge


    Q: could you arrange the production education?
    A: Yes , we could and the buyer pay the charge


    Q:How long the guarantee?
    A: one year and charge for repair the whole life.


    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
