    Bath Fitting Faucet Brass Gravity Die Casting Machine Production Line

    Ask Lasest Price
    Brand Name : DZ
    Model Number : HZ-450
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 Sets per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Bath Fitting Faucet Brass Gravity Die Casting Machine Production Line

    Bath Fitting Faucet Brass Gravity Die Casting Machine Production Line


    Faucet Brass Casting Production Line Bath Fitting Casting Machine Gravity Die Casting Machine

    Ⅰ CHARACTERISTIC
    1) the circuit is controlled by PLC, the data is set by touch screen and all hydraulic components are imported.
    2) It is suitable for gravity die casting of brass and ferrous alloy.
    3) It can be frontal casting, side casting, twice casting and mixed casting.
    4) It is possible to individually adjust the cooling time of the die.
    5) It facilitates the decomposition, combination and cleaning of dies.
    6) It has two functions manual and automatic circulation, the counter can be preset, to record the output of each shift.
    7) There is a die adjustment space to facilitate the application of different dies, and reduce the requirements for the die size.
    8) The machine can store the die casting operation programs and set the password accordingly.
    Ⅱ TECHNICAL PARAMETERS

    1MAX MOULD SIZE450mm
    2Max Mould Weight130KG
    3Longest Merger Distance≤250mm
    4Hydraulic Pressure40-60KPa
    5Side Casting Angie0º-90º
    6Frontal Casting Angle0º-110º
    7Hydraulic Oil163L
    8Total Power5.5KW
    9Installing Top Core Device20mm travel
    10Net Weight1750KG
    11Machine Dimension2250*2160*1560mm

    Bath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production LineBath Fitting Faucet Brass Gravity Die Casting Machine Production Line

    FAQ

    Q: Could you please arrange the installation and commissioning ?
    A: Yes , we could and the buyer pay the charge.
    Q: Could you arrange the production education?
    A: Yes , we could and the buyer pay the charge.
    Q: How long the guarantee?
    A: One year and charge for repair the whole life.
    Q: How about the lead time and delivery time of my order?
    A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
