Brass Water Meter Polishing Machine For Polishing Door Handle And Faucet

Ask Lasest Price
Brand Name :	DZ
Model Number :	NC-64
Certification :	CE ISO
Price :	egotiable
Payment Terms :	T/T
Supply Ability :	30sets / month
Delivery Time :	20 work days

Add to Cart

Product Details
Company Profile

Brass Water Meter Polishing Machine For Polishing Door Handle And Faucet

Detail Information
Dimensions (LWH):	440034002900	Machine Power:	35KW
Rated Voltage:	380V	Max. Diameter Of Polishing Wheel:	600mm
Min. Diameter Of Polishing Wheel:	400mm	X-Axis Travel (mm):	1200
Y-Axis Travel (mm):	1100	Z-Axis Travel (mm:	700
U-Axis Travel (mm):	±90°	V-Axis Travel (mm):	±360°
W-Axis Travel (mm):	±360°
High Light:	Water Meter CNC Buffing Machine,Brass Water Meter Casting Machine, 380V Door Handle Polishing Machine

Product Description

Features of various polishing machines on the market

No	project	DingZhu polishing machine	Robotic polishing machine	Special polishing machine	Remarks
1	quality	high	medium	low
2	flexibility	Universal Angle, ensure that not deformation does not leakage	Universal Angle, ensure that not deformation does not leakage	Easy to deformation and leakage
3	Wheel flexibility	The wheel is large to ensure the line speed and the wheel is flexible	The wheel is large to ensure the line speed and the wheel is flexible	The wheels are small and not very flexible enough
4	rigidity	Good steel, the wheels can be pressed tightly and polished	Arms are too long, with poor steel performance	Good steel, the wheels can be pressed tightly and polished
5	productivity	high	low	higher
6	Add wax	Solid wax, uniform, economical, and environmentally friendly	Liquid wax has a high cost, poor effect, and pollutes the equipment and the environment	Liquid wax has a high cost, poor effect, and pollutes the equipment and the environment
7	Wheel loss	low	low	high
8	self-compensating	Coordinate and line speed compensation effect is good	Without this function, it affects the quality	Without this function, it affects the quality
9	frock	Small quantity, simple structure, low cost	Small quantity, simple structure, low cost	The number is very large, complex structure, high cost
10	Programming time	Within 2 hours	8 Hours	8 Hours
11	Programming difficulty	Simple	Complicated	Complicated
12	Change the product	15 Minutes	2 Hours	8 Hours	Previous production procedures exist
13	safety	high	medium	low

DingZhu polishing machine product characteristics:

1. Automatic compensation function of polishing wheel: when the polishing cloth wheel is lost, the system can detect that the torque becomes smaller and realize automatic compensation in all directions.

2. Linear speed compensation: when the outer diameter of the cloth wheel decreases, the system automatically increases the speed compensation linear speed.

3. Solid wax addition: the original solid wax addition can freely set the wax addition time and frequency according to the characteristics of the product, and the polishing wax is not wasted.

4. Full digital control, the program can be saved and called at any time.

5. There are few fixtures, which can be replaced quickly and flexible universal, so as to reduce the loss of polishing cloth wheel.

6. The whole is polished evenly, and the quality of polished parts is consistent without deformation.

A fully automatic polishing machine that can replace 6 polishers to help you break through the bottleneck of die casting polishing

It can effectively improve the following aspects

1. Efficiency; It can be produced in 24 hours.

2. Quality: realize polishing standardization.

3. Save labor cost; The related expenses and management of personnel are controllable.

4. Safety and environmental protection, closed polishing production, equipped with dust suction interface,

5. The cost is controllable, the patented solid wax mechanism, and the cost of consumables is low.

6. Polishing versatility, applicable to various shapes of zinc aluminum copper stainless steel materials.

TECHNICAL PARAMETERS

No	Items	Specifications
1	Dimensions (LWH)	300031002900mm
2	Machine Power	17KW
3	Rated Voltage	380V
4	Max. Diameter of polishing wheel	600mm
5	Min. Diameter of polishing wheel	400mm
6	X-Axis travel (mm)	1100
7	Y-Axis travel (mm)	900
8	Z-Axis travel (mm)	700
9	U-Axis travel (mm)	±60°
10	V-Axis travel (mm)	±360°
11	W-Axis travel (mm)	±360°
12	Max.speed X axis	20m/min
13	Max.speed Y axis	20m/min
14	Max.speed Z axis	20m/min
15	Max.speed U axis	30°/sec.
16	Max.speed V axis	30°/sec.
17	Max.speed W axis	30°/sec.

Brass Water Meter Polishing Machine For Polishing Door Handle And Faucet

Packing and Shipping:

Packaging and Shipping for Automatic Polishing Machine

The Automatic Polishing Machine is carefully packaged in a durable cardboard box to ensure it is delivered in perfect condition.

The box is then taped shut and labeled with the necessary shipping details, such as the shipping address, product weight, and dimensions.

Once the package is prepared, it is shipped via a reliable carrier, such as UPS or FedEx, to the destination.
