    Low Pressure Die Casting Machine: Fast, Efficient and Durable

    Ask Lasest Price
    Brand Name : DZ
    Model Number : RD-7050-S
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1 set /per month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Low Pressure Die Casting Machine: Fast, Efficient and Durable

    Product Description:

    Low Pressure Die Casting Machine is a high-precision industrial machine that is used for casting metals and alloys. It is suitable for casting products with high accuracy, surface finish and dimensional stability.

    Low Pressure Die Casting Machine: Fast, Efficient and DurableLow Pressure Die Casting Machine: Fast, Efficient and DurableLow Pressure Die Casting Machine: Fast, Efficient and DurableLow Pressure Die Casting Machine: Fast, Efficient and DurableLow Pressure Die Casting Machine: Fast, Efficient and Durable

    Features:

    • Product Name: Low Pressure Die Casting Machine
    • Melting Rate: 350KG/H
    • Total Weight: 13T
    • Voltage: 380V
    • Furnace Capacity: 1800KG
    • Equipment Size: L*W*H: 5200*5000*3600mm
    • Features: Automatic Casting Machine, Metal Dia Casting Machine

    Technical Parameters:

    PropertiesParameters
    Equipment Size:L*W*H5200*5000*3600mm
    Total Weight13T
    Total power125KW
    Voltage380V
    Max. Die Dimensions600*400*240mm
    Max. Die Thickness2*120mm
    Max. Die Opening stroke370mm
    Max.Die Weight200Kg
    Max. force of die closing2400KG
    Max. force of ejector500KW
    Max. die ejector stroke48mm
    Furnace Melting rate350KG/H
    Furnace Capacity1800KG
    Furnace Inductors3*35KW
    Hydraulic Motor Power8.7KW
    Hydraulic Rated Pressure8Mpa
    Hydraulic fluid temperature≤52℃
    Cooling system Water PH value7~8.5
    Cooling system Pressure3-5bar
    Cooling system Temp.20±2℃
    Cooling system Flow≥400L/Min ≤600L/Min
    Air pressure Compressed air pressure0.5-0.6Mpa
    Air pressure Compressed air consumption15m³/H

    Applications:

    • Suitable for casting brass parts

    Packing and Shipping:

    Packaging and Shipping of Low Pressure Die Casting Machine

    The Low Pressure Die Casting Machine is securely packaged and shipped to the customer's location with the utmost care. It is packed in special boxes to protect the machine from any damage during transportation. The package includes the machine, user manual, and other accessories. The package is then sealed and labeled for shipping.

    The Low Pressure Die Casting Machine is shipped via a reliable freight carrier. The shipping cost is based on the size, weight, and delivery destination of the package. The customer will be kept informed of the shipment status at all times.

    FAQ:

    Q: What is the brand and model of the Low Pressure Die Casting Machine?
    A: The brand is DZ and the model is RD-7050-S.
    Q: Where is the Low Pressure Die Casting Machine manufactured?
    A: The Low Pressure Die Casting Machine is manufactured in China.
    Q: Does the Low Pressure Die Casting Machine have any certifications?
    A: Yes, the Low Pressure Die Casting Machine has CE and ISO certifications.
    Q: What is the size of the Low Pressure Die Casting Machine?
    A: The size of the Low Pressure Die Casting Machine depends on your specifications.
    Q: What types of materials can be used in the Low Pressure Die Casting Machine?
    A: The Low Pressure Die Casting Machine is capable of processing a variety of materials, including aluminum, zinc, and copper alloys.
