Product Description:
High-Performance Peeling Machine - Accurate,Bathroom Die Casting
Surface Peeling Processing
The Peeling Machine (New) is a heavy-duty machine designed to
remove burrs, oxidized skin and other surface defects from the
surface of castings.
Features:
- The three-axis adopts high-precision ball guide rail, which can
quickly shift 48m, greatly improving the speed and saving time.
-Elongated table design, can be installed at the same time
multi-workpiece position, spindle using multi-head high-power
electric spindle, can simultaneously multi-workpiece processing,
improve efficiency.
-The headstock adopts nitrogen counterweight balancing mechanism to
ensure the high speed and stability of the headstock.
-The best bed mechanism design, the rear outlet water tank position,
easy to use, the whole machine beautiful.
Technical Parameters:
| Product Name | Technical Parameters |
| Peeling Machine (New) | Whole machine weight(about): 3500kg |
| Workbench size | 1050*420mm |
| T-groove(number*slot*width) | 3-18*125mm |
| Maximum load(acerage distribution of workbench) | 350kg |
| Three axis stroke | 500*400*400mm |
| Spindle nose to table surface | 150-500mm |
| Distance between the center of the spindle taper(model/installation
size) | 450mm |
| Spindle taper(model/installation size) | electric spindleER20/25/35 chuck form |
| Spindle speed | standard configuration:18000rpm optional configuration:24000rpm |
| Tool Number | No tool magazine:4/electric spindle |
| Maximum tool diameter available | 2/4/6/8/10/12/13mm |
| Three axis fast feed speed | 48/48/48m |
| Feed rate | 0-10000mm |
| Precision | ±0.005/300mm |
| Repetition is defined as precision | ±0.005/300mm |
| Spindle drive motor | 4*4.0kw/4.5.5kw |
| Land area(long*width*high) | 2300*2400*2400mm |
| Whole machine weight(about) | 3500kg |
Applications:
Focus on bathroom, hardware products industry die casting, casting
surface peeling processing
Packing and Shipping:
Packaging and Shipping for Peeling Machine (New)
The Peeling Machine (New) is packaged securely in a cardboard box.
The box is large enough to fit the machine and all of its
accompanying parts. Inside the box, all of the components are
carefully placed in separate compartments. A detailed instruction
manual is included for easy assembly. All of the parts are securely
fastened with bubble wrap or foam to prevent damage during
shipping.
The Peeling Machine (New) is shipped via a reliable courier
service. Tracking information will be provided to the customer upon
shipment. The estimated delivery time is within 3-5 business days
from the date of order.
FAQ:
Q1: What is the brand of the Peeling Machine (New)?
A1: The brand of the Peeling Machine (New) is DZ.
Q2: What is the model number of the Peeling Machine (New)?
A2: The model number of the Peeling Machine (New) is XYT-DK540-4.
Q3: Where is the Peeling Machine (New) made?
A3: The Peeling Machine (New) is made in China.
Q4: What is the purpose of the Peeling Machine (New)?
A4: The Peeling Machine (New) is designed to quickly and easily
peel fruits and vegetables.
Q5: What are the features of the Peeling Machine (New)?
A5: The Peeling Machine (New) features a powerful motor, adjustable
speed, and a stainless steel blade for precision peeling.
